OVERVIEW

The company that invented the big fans that have become so popular in industrial and commercial spaces has created the next generation of high-volume, low-speed fans (HVLS fans). Introducing AirVolution-D. Take a look at the side-by-side comparison between the new AirVolution-D and conventional large ceiling fan design used by competitors like Big Ass Fans. You’ll see the advantages in power, efficiency, intelligence, and reliability at every turn.


Airvolution 370
  • Small Space Solution
  • 6′ to 12′
  • 52 to 74 lbs
  • 0.25 hp
  • 9.6 ft-lb
  • Ideal for smaller spaces. Sleek looks and two custom color options add to its appeal, allowing it to blend with any setting. For small spaces like offices, restaurants, and lobbies, the AirVolution-D Model 370 is a perfect fit.
AirVolution 550
  • Medium to Large Spaces
  • 8′ to 18′
  • 144 to 188 lbs
  • 1.05 hp
  • 51.6 ft-lb
  • For medium to large spaces, the AirVolution-D fan is extremely effective at controlling temperature and humidity. Ideal locations include auto shops, gymnasiums, and agricultural applications like dairy farms and equine facilities.
Airvolution 780
  • Extra-Large Spaces
  • 20′ to 24′
  • 214 to 239 lbs
  • 2.10 hp
  • 125.4 ft-lb
  • Designed for heavy-duty applications, the AirVolution-D Model 780 is perfect for extra-large spaces like warehouses, airplane hangars, airports, and stadiums. Lighter weight and easy mounting without guy wires or extra support systems.
Macroair D3
  • Medium to Large Spaces
  • 10′ to 24′
  • 129 to 162 lbs
  • 1.05 hp
  • 51.6 ft-lb
  • Designed to be the most cost-effective HVLS fan on the market today, the MacroAir AirVolution-D3 blows away our leading competitor’s entry-level model. For the first time, cost doesn’t have to be a barrier to an HVLS fan.
By eliminating the gearbox, we’ve eliminated the noise.  Quietest HVLS fan lineOnly 2 moving parts  No gear or friction noise

By eliminating the gearbox, we’ve eliminated the noise.

Quietest HVLS fan lineOnly 2 moving parts

No gear or friction noise

A direct-drive motor that’s 3× smaller yet 5× more powerful.  D-Drive, next-generation DC motorOnly 24’ direct-drive fan on the market  50% greater continuous horsepower

A direct-drive motor that’s 3× smaller yet 5× more powerful.

D-Drive, next-generation DC motorOnly 24’ direct-drive fan on the market

50% greater continuous horsepower

Advanced, upgradeable control for HVLS.  Ground level diagnostics via touchpad remote  Integrates into building automation systems via gateway

Advanced, upgradeable control for HVLS.

Ground level diagnostics via touchpad remote

Integrates into building automation systems via gateway


MacroAir Big Ass Fans
